I.Description

HZJS-1B Oil Particle Counter adopts Laser Extinction Technology, is designed to measure the particles’ size and quantity in oil liquid. It is Suitable for tests of pollution degree of solid particles in hydraulic oil, lubricating oil, fire resistant oil, insulating oil, turbine oil, organic liquid and polymer solution, etc. So our instrument can be used in aviation, spaceflight, electric power, petroleum, chemical industry, transportation, port, metallurgy, machinery, automobile manufacturing and many other fields.

II.Technical Data

Size Range 1μm-100μm

Channel 8 channel(size can be set free in the range of selected curve)

Sample Volume ≥0.2ml

Sample Speed 5ml/min~80ml/min

Resolution ＜10%

RSD ＜2%

Coincidence deviation limit 10000/ml

Range of Pressure low: 0~6bar High:3~400bar

Viscosity ＜350cst

Storage Space 100 set

Power Supply AC220V±10%；50Hz；≤200W

Battery 5200mA； 6~8h

Data Output RS232 and printer inside
