I. Functional Features

◆ The instrument can replace similar foreign products.

◆ The main components are imported products (temperature controller, deposition rod, gear pump, flow sensor etc.);

◆ The instrument can set the working time and automatically stop after the test;

◆ The instrument can be tested by ASTM D6335,SH/T0750 method through the addition of parts;

◆ The instrument is equipped with catalyst magnetic mixing device, which can set mixing time and mixing speed;

◆ Automatic electronic flow controller, accurate control of gas flow rate 10ml±0.2ml/min;

◆ All parameters can be set on the touch screen, and the test can be started with one key after completion;

II. Scope Of Application

◆ Lubricating oil production enterprise

◆ Testing Department

III. Relevant Standards

◆ASTM D7097《Test method for the determination of moderately High Temperature piston deposits by hot oxidized oil simulation test》

◆SH/T0834《Engine oil - Determination of moderately high temperature piston deposits - thermal oxidation simulation test method（

TEOST MHT）》

◆SH/T0750《Method for determination of high temperature oxidized deposits in engine oils(thermal oxidation simulation test method)》

IV. Technical Parameters

Applicable standard: ASTM D7097, SH/T0834 or SH/T0750

Test temperature: normal temperature ~ 500℃±2℃

Test duration: 24 hours

Sample size: 8.4g

Pump flow rate: 0.25 g/min

Gas flow rate: 10ml±0.2ml

Power supply: AC220V 50Hz

Instrument size: 450*450*560mm
